Part No.: YPMW1560HB-DCL01 - Case 6-109798 - Question: LCD back Fan model replacement.

Customer issue:
Installed fan at back of LCD failed.

Solution:
Fan model is FANTECH fd1250-e1012a, you can buy online as long as it meets the following specifications can work:

(1) size 50x50x10 mm (2) voltage DC12V.

For example: Sunon MF50101V1 Series can be.

Reference picture.
